EN DIN BS 1.4435 X2CrNiMo18-14-3 Bright Stainless Steel Round Bar
EN DIN BS 1.4435 X2CrNiMo18-14-3 Bright Stainless Steel Round Bar
Model
1.4435

Item specifics

Surface condition
Black, Blasted, Turned, Polished

Review

Description

1.4435 X2CrNiMo18-14-3 Austenitic Stainless Steel



Introduce

1.4435 is an acid-resisting austenitic CrNiMo-Steel with 18% Cr, approx. 14% Ni and at least 2.5% Mo. Due to the increased Mo-content, this material has a significantly improved corrosion resistance compared to other CrNi-Steels. 1.4435 is particularly resistant to reducing effecting organic and anorganic organic acids as well as against halogen-containing media. Furthermore, this steel is also less susceptible to pitting. The very low carbon content also improves the resistance to intergranular corrosion, allowing the use of this steel at elevated temperatures up to 450 ° C in continuous operation. 1.4435 can also be very well polished, very good deformable and can be welded excellent.



Our supply size:

Diameter : 80 to 600 mm ;

Length : 1000 to 9000 mm ;



Our advantage:

1. High Quality, Reasonable Price

2. Over 40 Years Experience

3. ISO NQA Certificated Factory

4. Worldwide shipping

5. Emergency Orders and Fast Delivery



Equivalent grades of steel X2CrNiMo18-14-3 (1.4435)

EU

USA

Germany

Japan

France

England

Italy

EN

-

DIN,WNr

JIS

AFNOR

BS

UNI

X2CrNiMo18-14-3

316L

X2CrNiMo18-14-3

SUS316L

Z3CND17-12-03

316S13

X2CrNiMo17-13



Chemical composition % of steel X2CrNiMo18-14-3 (1.4435): EN 10088-2-2005

C

Si

Mn

Ni

P

S

Cr

Mo

N

max 0.03

max 1

max 2

12.5 - 15

max 0.045

max 0.015

17 - 19

2.5 - 3

max 0.11



Equivalent grades of steel X2CrNiMo18-14-3 (1.4435)

Rm - Tensile strength (MPa) (+A)

490-700

Rm - Tensile strength (MPa) (+AT)

490-690

Rp0.2 0.2% proof strength (MPa) (+A)

190-240

Rp0.2 0.2% proof strength (MPa) (+AT)

190-200

  Brinell hardness   (HB):   (+A)

215

  Brinell hardness   (HB):   (+AT)

200



Application

Construction encasement, doors, windows and armatures, offshore modules, cisterns and pipes for chemical tanks, production, warehousing and over land transportation of chemicals, food and beverages, pharmacy, synthetic fibre, paper and textile plants and pressure vessels. Due to the low C-content, the resistance to intergranular corrosion is also guaranteed in the welded condition.



Smelting Option

1 EAF: Electric Arc Furnace

2 EAF+LF+VD: Refined-smelting and vacuum degassing

3 EAF+ESR: Electro Slag Remelting

4 EAF+PESR: protective atmosphere Electro Slag Remelting

5 VIM+PESR: Vacuum induction melting



Forming Option

1 Hot rolling process

2 Hot Forging: Electro-hydraulic; High-speed-hydraulic; Oil-hydraulic; Precision-forging



Heat-treatment Option

1 +A: Annealed (full/soft/spheroidizing)

2 +N: Normalized

3 +NT: Normalized and tempered

4 +QT: Quenched and tempered (water/oil)



Surface Option

1 Black Surface

2 Grounded: Bright but rough ; Not precision

3 Machining for plate: Bright and precision; Little turning scar

4 Peeled/Turned: Bright and precision; Little turning scar

5 Polished: Very Bright and precision size; Not turning scar



Other Services

1 Cutting: Small pieces

2 CNC Machine: Produce as your drawing

3 Package: Bare/Nylon/Canvas/Wooden

4 Payment:T/T, L/C, O/A(request credit)

5 Transport:FOB/CFR/CIF/DDU/DDP (train/ship/Air)



Mill test certificate

EN 10204/3.1 with all relevant data reg. chem. composition, mech. properties and results of testing.
