X210Cr12 Cold Work Tool Steel

Premium 12% Chrome Tool Steel from FUSHUN METAL

Steel Grade Introduction and Applications

X210Cr12 (also known as D3, 1.2080, SKD-1) is a premium 12% chrome compound steel manufactured by FUSHUN METAL. This cold work tool steel delivers exceptional performance in demanding industrial applications where high wear resistance and dimensional stability are critical requirements.

The steel features high wear resistance against both abrasive and adhesive wear due to the high volume of hard carbides in the steel matrix. With medium toughness and excellent dimensional stability, X210Cr12 provides reliable performance in high-stress applications.

Primary Applications:

Blanking and Forming Dies
High precision cutting and forming operations
Forming Rolls
Metal forming and shaping applications
Press Tools
Heavy-duty pressing operations
Punches and Bushes
Precision tooling components

Chemical Composition, Mechanical Properties & Heat Treatment

Chemical Composition

Element C Si Mn S P Cr
Content (%) 1.90-2.20 0.01-0.60 0.20-0.60 ≤0.03 ≤0.03 11.00-13.00

Physical & Mechanical Properties

Property Metric Imperial
Density 7.7 × 10³ kg/m³ 0.278 lb/in³
Melting Point 1421°C 2590°F
Izod Impact (Unnotched) 28.0 J 20.7 ft-lb
Elastic Modulus 190-210 GPa 27557-30457 ksi
Poisson's Ratio 0.27-0.30

Heat Treatment Parameters

Treatment Temperature Holding Time Cooling Hardness
Annealing 800-840°C 2 min/mm Furnace MAX 250 HB
Stress Relieving 650-700°C 2 min/mm Furnace -
Hardening 930-980°C 1 min/mm Air/Oil (≤30mm) 64 HRC

Available Sizes from FUSHUN METAL

FUSHUN METAL maintains comprehensive inventory of X210Cr12 cold work tool steel in various sizes to meet diverse industrial requirements. Our standard sizes are readily available from stock for immediate delivery.

Standard Stock Sizes Available:

Round Bars: Diameter 10mm to 500mm, Length up to 6000mm

Flat Bars: Thickness 5mm to 200mm, Width up to 1000mm

Square Bars: 10mm × 10mm to 300mm × 300mm

Plates: Thickness 10mm to 300mm, Custom dimensions available

Stock Advantage: Standard sizes are maintained in inventory for fast delivery and competitive pricing.

Custom Manufacturing: We accept custom orders for non-standard dimensions. Please contact us to discuss your specific size requirements and production capabilities.

Quote Request: Contact FUSHUN METAL today for pricing on standard sizes or custom manufacturing solutions.

FUSHUN METAL Advantages

Fast Stock Delivery

Extensive inventory ensures rapid delivery of standard sizes, minimizing your project downtime and maintaining production schedules.

Integrated Manufacturing Network

Strategic partnerships with leading Chinese steel producers ensure consistent quality, competitive pricing, and reliable supply chain management.

Precision Machining Services

Complete machining capabilities including turning, grinding, and finishing services to deliver ready-to-use components, saving time and costs for downstream customers.

Technical Expertise

Professional technical support and consultation services to help customers select optimal steel grades and heat treatment parameters for their specific applications.

Contact FUSHUN METAL Today

Experience the FUSHUN METAL advantage in tool steel supply. Contact us for competitive quotes, technical consultation, and reliable delivery solutions for your X210Cr12 requirements.
