1.2358 / X60CrMoV18-5 Cold Work Tool Steel

Chrome-molybdenum-vanadium steel is characterized by high toughness and good resistance to the wear. Further the steel has good hardenability and good dimensional stability after hardening and tempering. The steel can also be well welded and well polished. The toughness of quality 1.2358 reaches higher values than by other steels for cold work (1.2842, 1.2363, 1.2080, 1.2379, 1.2436). An excellent combination of toughness and resistance to the wear enables the usage of quality 1.2358 also for different pressing and injection applications during plastics processing.



Applications

For cold work and for molds for plastics. In case of using for cold work we can talk mainly about these applications: cutting and mechanical working (also materials of bigger thicknesses), deep drawing, punching, rolling, production of shear blades, more complicated tools for cold work. In the area of molds for plastics the steel can be used e.g. for molds for large series, molds for plastics with additives, tools for plastics stamping etc.



Equivalent

Standards: X60CrMoV18-5

DIN: 1.2358



Chemical composition (typical analysis in %)

Standard

Steel Grade

Chemical composition %

C:

Mn:

Si:

P:

S:

Cr:

Mo:

V:

DIN/EN

1.2358 - 60CrMoV18-5

0.58 - 0.62

0.7 - 0.9

0.2 - 0.5

<0.03

<0.03

4.3 - 4.7

0.4 - 0.6

0.2 - 0.3



Size range

Diameter (mm)6 - 500 Thickness (mm)6 - 400 Width (mm)Max 810



Delivery condition

Soft annealed to max. 240 HB



Mechanical properties of 60CrMoV18-5, 1.2358

Hardness in annealed condition +A: <235HB

Hardness after hardening and tempering at temperature:

200C = 58HRC

300C = 56HRC

350C = 55HRC

500C = 53HRC

550C = 50HRC

Thermal conductivity 200/400C = 27/13 W*m*K

Thermal capacity, cp 20/200/400C = 455/525/608 J*Kg*K



Heat treatment - processes and temperatures:

Softening annealing at a temperature of 820 - 860C

Stress relief annealing at a temperature of 600 - 650C

Hardening at a temperature of 950-970C with cooling in oil or salt bath

Tempering at temperature of >180C



Suitability

Steel W. Nr. 1.2358 can be used both for cold work and for molds for plastics. In case of using for cold work we can talk mainly about these applications: cutting and mechanical working (also materials of bigger thicknesses), deep drawing, punching, rolling, production of shear blades, more complicated tools for cold work. In the area of molds for plastics the steel can be used e.g. for molds for large series, molds for plastics with additives, tools for plastics stamping etc.
