O7 Cold Working Tool Steel



Introduction:

O7 Cold Working Die Steel is one kinds of oil hardening cold working die steel, which consists of chromium and manganese, and has higher tungsten content than grade O1. The O7 steel has the best wear resistance among the O series steels, however, it has relatively low hardenability.



Applications:

Cutting and punching tools for sheet thickness up to 6 mm, also for paper and plastics, roll shear blades for sheet thickness up to 6 mm, small bending and drawing tools, thread cutting tools, reamers, woodworking tools, gauges and other measuring tools, small inserts and plastic moulds.



Quality Standard:

ASTM A681 – 08 Standard Specification for Tool Steels Alloy.

BS EN ISO 4957 Tool Steel

JIS G4404 Alloy Tool Steel



All Grades Comparison:

ASTM

Material No.

EN

JIS

GB

O7

1.2419

105WCr6

SKS31

CrWMn



Chemical Composition(%)

Steel Grade

C

Si

Mn

P

S

Cr

V

W

Mo

O7

1.10-1.30

0.10-0.60

0.20-1.00

0.030 max

0.030 max

0.35-0.85

0.15-0.40

1.00-2.00

0.30 max

SKS31

0.95-1.05

0.35 max

0.90-1.20

0.030 max

0.030 max

0.80-1.20

/

1.00-1.50

/

105WCr6

1.00-1.10

0.1-0.40

0.80-1.10

0.030 max

0.030 max

0.90-1.10

/

1.00-1.30

/

CrWMn

0.90-1.05

0.40 max

0.80-1.10

0.030 max

0.030 max

0.90-1.20

/

1.20-1.60

/



HEAT TREATMENT:

 FORGING: Hot forming temperature: 1050-850oC

 SOFT ANNEALING: Heat to 720-750oC, cool slowly in furnace. This will produce a maximum Brinell hardness of 230.

 STRESS RELIEVING:Stress relieving to remove machining stresses should be carried out by heating to approx. 650oC, holding for 1-2 hours at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.

 HARDENING:Harden from a temperature of 800-830oC followed by oil quenching or warm bath quenching approx. 200oC. Hardness after quenching is 63-65 HRC.

 TEMPERING: Tempering temperature: See the data bellow.

Tempering Temperature

Hardness(HRC)

100oC

64

200oC

61

300oC

58

400oC

54

500oC

49

600oC

41

650oC

30



Mill′s test certificate:

EN 10204/3.1 with all relevant data reg. chem. composition, mech. properties and results of testing.
